Melting Point System MP90

Get a Price/Quote

Product Details:

Temperature Range Ambient +10C to 350C
Frequency 50/60 Hz
Capacity 3 capillaries simultaneously
Automation Grade Semi-automatic
Usage Laboratory
Feature User programmable ramp rates, Fast cooling, Bright LED illumination
Material NEW
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Melting Point System MP90 Price And Quantity

Minimum Order Quantity 1 Unit

Melting Point System MP90 Product Specifications

Usage Laboratory
Feature User programmable ramp rates, Fast cooling, Bright LED illumination
Temperature Range Ambient +10C to 350C
Dimension (L*W*H) 210 x 175 x 165 mm
Equipment Materials Metallic Body with Glass Viewing Window
Automation Grade Semi-automatic
Weight Approx. 4 kg
Capacity 3 capillaries simultaneously
Frequency 50/60 Hz
Display Type Digital LCD display
Measurement Range Up to 350C
Voltage 230 V AC
Type Bench-top Melting Point Apparatus
Model No MP90
Power Source Electric
Core Components Heater, Capillary tubes, Display, Controller
Material NEW
Accuracy 0.5C

Compliance CE certified
Heating Rate Adjustable, 0.5 to 10C/min
Calibration Digital, user-friendly interface
Operating Environment Temperature: 10C to 35C, Humidity <80% RH
Controller Type Microprocessor based temperature control
Sample Capacity 3 samples at a time
Safety Features Overheating protection, Protected viewing window
Capillary Tubes Standard open-ended glass capillaries
Cooling System Integrated fast cooling fan
Sample Observation Magnifying lens with illuminated sample chamber
Applications Pharmaceutical, Chemical, Academic research laboratories

Product Description

Optimized for highest throughput, the MP90 offers simultaneous determination of up to 6 melting point/melting range samples up to a maximum temperature of 400C/750F.

Brand	Mettler Toledo
Capacity	RT - 400C
Model	MP90
CAT No.	30578105

Accurate Simultaneous Measurements

The MP90 allows the melting points of up to three samples to be determined simultaneously, improving laboratory efficiency and productivity. Its microprocessor-based temperature control and high accuracy of 0.5C ensure reliable and repeatable results each time. This capability makes it especially suitable for busy laboratories requiring high throughput and precision.

User-Friendly and Safe Operation

Designed with laboratory safety and ease-of-use in mind, the MP90 features an overheating protection system, protected viewing window, and intuitive digital interface. The illuminated magnifying lens enables detailed observation, even with small or challenging samples. Programmable ramp rates and fast cooling facilitate smooth, safe, and customizable operation for a wide range of applications.

Versatile Applications Across Industries

Meeting stringent CE standards, the MP90 is widely adopted in pharmaceutical, chemical, and academic research laboratories. Its robust construction, adjustable heating, and wide temperature range (ambient +10C up to 350C) allow for diverse laboratory protocols. Its compact design and integrated features make it suitable for both routine use and specialized research requirements.

FAQ's of Melting Point System MP90:

Q: How do I operate the Melting Point System MP90 for multiple sample testing?

A: To test up to three samples simultaneously, insert each into separate standard open-ended glass capillaries and place them in the sample chamber. Set your desired heating rate and temperature range using the digital interface, then observe samples through the illuminated viewing window as they heat.

Q: What safety features does the MP90 provide during operation?

A: The MP90 includes an overheating protection system and a protected viewing window to ensure safety. Its metallic body and glass viewing panel are designed to minimize risks, while stable temperature control helps prevent accidental overheating.

Q: When should I calibrate the MP90 and how is it done?

A: Calibration should be performed regularly, especially before critical measurements or after extended periods of non-use. The process is digital and user-friendly-simply follow the on-screen instructions to access the calibration mode and use a certified reference standard for best results.

Q: Where can the MP90 Melting Point Apparatus be used?

A: This system is suitable for controlled laboratory environments such as pharmaceutical, chemical, or academic research labs. It operates optimally within a temperature range of 10C to 35C and under humidity levels below 80% RH.

Q: What are the benefits of the MP90's integrated cooling system?

A: The integrated fast cooling fan allows the unit to return quickly to baseline temperatures after measurements, increasing throughput and reducing waiting times between sample runs.

Q: How does the digital LCD display enhance sample observation and results recording?

A: The digital LCD display provides clear, real-time readings of temperature and status, allowing for accurate monitoring and easy documentation of results during experiments.

Q: What types of capillary tubes can be used with the MP90?

A: The MP90 is compatible with standard open-ended glass capillaries, making it convenient to source consumables and replace them as needed.
