Arkray Spotchem EL SE-1520 Electrolyte Test Analyzer

Get a Price/Quote

Product Details:

Wall Mounted No
Application Measurement of Sodium, Potassium, Chloride and Lithium in Whole Blood, Serum, Plasma, and Urine
Power Consumption Approx. 80 VA
Attributes High Precision, Compact Design, Fast Processing
Color White / Light Grey
Material High-grade ABS Plastic, Stainless Steel Internal Components
Shape Rectangular Compact
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Arkray Spotchem EL SE-1520 Electrolyte Test Analyzer Price And Quantity

Arkray Spotchem EL SE-1520 Electrolyte Test Analyzer Product Specifications

Real-Time Operation Yes
Set Contains Main Unit, Power Adapter, Electrolyte Standards, Accessories
Power AC Adapter
Accuracy 2% (for Na+ and K+)
Suitable For Use Clinical Laboratories, Hospitals, Diagnostic Centers
Operation Mode Fully Automatic
Capacity 40-60 Samples/Hour
Size Compact, Tabletop
Technology Ion Selective Electrode (ISE)
Portable Yes
Voltage 100-240 V, 50/60 Hz
Feature Automatic Calibration, Error Detection, LCD Display, Rapid Results
Operating Type Automated, Touch Keypad
Condition New
Dimension (L*W*H) Approximately 270 mm 350 mm 150 mm
Function Electrolyte Analysis
Storage Instructions Store in Cool, Dry Place, Avoid Direct Sunlight
Use Laboratory Electrolyte Testing (Na+, K+, Cl-, Li+)
Noise Level Low
Equipment Type Electrolyte Test Analyzer
Shape Rectangular Compact
Material High-grade ABS Plastic, Stainless Steel Internal Components
Color White / Light Grey
Attributes High Precision, Compact Design, Fast Processing
Power Consumption Approx. 80 VA
Application Measurement of Sodium, Potassium, Chloride and Lithium in Whole Blood, Serum, Plasma, and Urine
Wall Mounted No

Sample Volume 50100 L per test
Sample Types Whole Blood, Serum, Plasma, Urine
Printer Built-in Thermal Printer
Operating Temperature 15C - 35C
Status Indicator LED and Audible Alerts
Sample Tray Single position, Manual Loading
Calibration Fully Automated, Programmable
Cleaning Method Automatic Probe Cleaning
Throughput Approximately 60 samples per hour
Humidity Range 20% - 85% RH (non-condensing)
Display Large LCD Display with User-Friendly Interface
Data Interface RS232C, Printer Port
Testing Parameters Sodium (Na+), Potassium (K+), Chloride (Cl-), Lithium (Li+)

Arkray Spotchem EL SE-1520 Electrolyte Test Analyzer Trade Information

Supply Ability 1000 Unit Per Day
Delivery Time Week

Product Description

Brand	Arkray
Sample Type	Serum/ Plasma/ WB
Test Type	Electrolyte
CAT No	SE-1520

SPOTCHEM EL is an electrolyte analysis system with capacity for total electrolyte analysis requirements in all fields.

Efficient, High-Precision Testing

Achieve reliable and rapid results with the Arkray Spotchem EL SE-1520. Capable of processing 40-60 samples per hour, this analyzer utilizes ISE technology to ensure high precision (2% accuracy for Na+ and K+). Its automatic calibration and probe cleaning features optimize operational efficiency and reduce maintenance needs, ideal for busy clinical settings.

User-Friendly Operation and Design

Featuring a large LCD display and intuitive touch keypad, the Spotchem EL SE-1520 offers a user-friendly interface for quick start-up and easy navigation. Its compact, lightweight construction makes it a perfect fit for any diagnostic workspace, while the automatic error detection and built-in thermal printer streamline routine laboratory workflows.

Comprehensive Sample Compatibility

This versatile analyzer is suitable for a variety of biological samples such as whole blood, serum, plasma, and urine. With programmable settings and real-time operation, it accommodates a wide range of clinical applications from routine health screenings to specialized electrolyte analysis in hospitals, clinics, and diagnostic centers.

FAQ's of Arkray Spotchem EL SE-1520 Electrolyte Test Analyzer:

Q: How does the Arkray Spotchem EL SE-1520 analyzer perform electrolyte tests?

A: The Arkray Spotchem EL SE-1520 uses Ion Selective Electrode (ISE) technology to conduct fully automated testing of sodium, potassium, chloride, and lithium. The analyzer only requires 50-100 L of the sample and delivers accurate results for whole blood, serum, plasma, and urine.

Q: What are the key benefits of using this electrolyte analyzer in a laboratory setting?

A: Key benefits include high throughput (up to 60 samples/hour), precise measurements (2% for Na+ and K+), compact and portable design, fully automated operation, prompt result printing via a built-in thermal printer, and intuitive user interface, making it ideal for clinical laboratories and hospitals.

Q: When should I calibrate the SE-1520, and is this process automated?

A: Calibration is fully automatic and programmable, ensuring consistent accuracy without manual intervention. The analyzer performs scheduled calibrations and can also conduct calibrations as part of the set-up or after maintenance, enhancing reliability in test results.

Q: Where can the Spotchem EL SE-1520 be installed or used?

A: The analyzer is designed for use in clinical laboratories, hospitals, and diagnostic centers. Its compact, tabletop build makes it suitable for various medical environments where space and portability are important.

Q: What is the process for loading and analyzing a sample?

A: Samples are manually loaded into a single-position tray. Upon loading, select the test parameters via the touch keypad; the device automatically aspirates, analyzes, and prints results. Cleaning of the probe is also automatic for quality assurance.

Q: How do the status indicators help during operation?

A: The analyzer features LED and audible alerts that provide real-time status updates, including completion of analysis, errors, or maintenance reminders, ensuring smooth and uninterrupted operation.
