Mindray Auto Hematology Analyzer BC-6800Plus

Mindray Auto Hematology Analyzer BC-6800Plus

Get a Price/Quote

Product Details:

Material High-grade industrial plastic and stainless steel body
Condition New
Technology Flow cytometry with SF Cube technology, fluorescence, and impedance
Portable No (Bench-top design)
Wall Mounted No
Light Source Semiconductor Laser ( = 635 nm)
Display Type 22-inch LCD touchscreen
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Mindray Auto Hematology Analyzer BC-6800Plus Price And Quantity

Input/Output Ports 2x USB, 2x RS-232, 1x LAN port
Quality Control Modes 3 levels; X-bar and L-J chart
Humidity Range 3085% RH (non-condensing)
Carryover WBC: 0.5%, RBC: 0.5%, PLT: 0.5%
Autoloader Capacity 100 samples continuous loading
Parameters Measured CBC, WBC Differential, NRBC, Reticulocyte, Body Fluids, PLT-O, PLT-I
Operating Temperature 15C32C
Flagging System Comprehensive abnormal cell flagging
Sample Volume (Whole blood) 80 L
Sample Mode Whole blood, pre-diluted, and body fluids
Pre-dilution Mode Supported
Reagent Management Barcode reagent management system
Throughput Up to 200 samples per hour (CBC + Diff)
Environmental Design Low reagent consumption, eco-friendly operation

Mindray Auto Hematology Analyzer BC-6800Plus Product Specifications

Wall Mounted No
Display Type 22-inch LCD touchscreen
Software Detail User-friendly embedded software with LIS connectivity
Size 730 mm 780 mm 720 mm (W D H)
Real-Time Operation Available with real-time QC and calibration monitoring
Voltage AC 100-240V, 50/60 Hz
Measurement Routine CBC + 5-part differential, NRBC, and Reticulocyte parameters
Light Semiconductor laser light source
Power Source Electric
Material High-grade industrial plastic and stainless steel body
Attributes High throughput, advanced clinical parameters, intuitive interface
Condition New
Synchronize With Laboratory LIS/HIS systems
Usage Laboratory hematology analyzer for blood analysis
Color White and grey
Data Transmission Mode USB, Ethernet, bidirectional LIS/HIS support
Operating Type Automatic
Technology Flow cytometry with SF Cube technology, fluorescence, and impedance
Portable No (Bench-top design)
Noise Level 65 dB
Sensor Integrated optical and electrical sensors for accurate detection
Light Source Semiconductor Laser ( = 635 nm)
Resolution 1920 x 1080 pixels
Weight Approx. 110 kg
Power Consumption 1000 VA
Internal Memory >100,000 sample results storage

Input/Output Ports 2x USB, 2x RS-232, 1x LAN port
Quality Control Modes 3 levels; X-bar and L-J chart
Humidity Range 3085% RH (non-condensing)
Carryover WBC: 0.5%, RBC: 0.5%, PLT: 0.5%
Autoloader Capacity 100 samples continuous loading
Parameters Measured CBC, WBC Differential, NRBC, Reticulocyte, Body Fluids, PLT-O, PLT-I
Operating Temperature 15C32C
Flagging System Comprehensive abnormal cell flagging
Sample Volume (Whole blood) 80 L
Sample Mode Whole blood, pre-diluted, and body fluids
Pre-dilution Mode Supported
Reagent Management Barcode reagent management system
Throughput Up to 200 samples per hour (CBC + Diff)
Environmental Design Low reagent consumption, eco-friendly operation

Product Description

Brand	Mindray
Model	BC-6800 Plus
Capacity	40 Test/Hr
CAT No	BC-6800 Plus
Application	Hematology

The advanced BC-6800Plus not only provides more reliable routine CBC plus 5-part DIFF results, but also has a higher throughput of up to 200 samples per hour. Based on the new SF Cube technology platform, the BC-6800Plus could provide more reliable blood cell results and abnormal cells flagging results with anticipated warning messages, exceeding clinicians expectations and setting a new standard for blood analysis.

Exceptional Throughput and Workflow Efficiency

Engineered for laboratories with demanding workloads, the BC-6800Plus processes up to 200 samples per hour. The autoloader accommodates 100 samples with continuous loading, significantly reducing hands-on time and maximizing productivity, making it perfect for high-volume settings.

Advanced Clinical Parameters and Accurate Detection

Utilizing SF Cube technology, semiconductor laser, and combined optical and electrical sensors, this analyzer delivers detailed CBC, 5-part differential, NRBC, reticulocyte, and body fluid results. Comprehensive flagging alerts operators to abnormal cells, supporting timely and informed clinical decisions.

User-Centric, Eco-Friendly Design

Operated through a large 22-inch LCD touchscreen and supported by user-friendly software, the BC-6800Plus emphasizes ease of use and data management. Its eco-friendly reagent consumption, efficient power use, and barcode reagent management contribute to sustainable lab operations.

FAQ's of Mindray Auto Hematology Analyzer BC-6800Plus:

Q: How does the Mindray BC-6800Plus streamline the blood analysis process in laboratories?

A: The BC-6800Plus supports high throughput, processing up to 200 samples per hour with an integrated autoloader and continuous loading feature. This automation, combined with a user-friendly touchscreen and software, streamlines workflow by reducing manual intervention and increasing operational efficiency.

Q: What parameters can be measured with the Mindray BC-6800Plus hematology analyzer?

A: This analyzer measures routine CBC, 5-part WBC differential, nucleated red blood cells (NRBC), reticulocytes, body fluids, and offers advanced platelet (PLT-O and PLT-I) analysis. It enables precise monitoring of a broad range of hematological and clinical indicators.

Q: When is pre-dilution mode beneficial and does the BC-6800Plus support it?

A: Pre-dilution mode is beneficial when sample volume is limited or when handling specimens with extremely high cell counts. The BC-6800Plus fully supports this mode, ensuring reliable results while accommodating various sample requirements.

Q: Where can the BC-6800Plus be installed and what are its space requirements?

A: Designed as a bench-top analyzer, the BC-6800Plus is suitable for installation in clinical or hospital laboratories. It requires an area to accommodate its dimensions (730 mm x 780 mm x 720 mm) and a stable power source (AC 100-240V, 50/60 Hz).

Q: What is the process for managing reagents on this analyzer?

A: Reagents are managed efficiently via a barcode-based system, ensuring accurate tracking, reducing errors, and simplifying replenishment. The system supports streamlined inventory control and reporting for seamless laboratory operation.

Q: How does the BC-6800Plus benefit laboratory operations?

A: Its high throughput, advanced flagging system for abnormal cells, reliable quality control modes, and robust connectivity (USB, RS-232, LAN, LIS/HIS) enhance diagnostic accuracy, workflow efficiency, and data security. The eco-friendly design and low reagent consumption further optimize lab resources.
