Truelab Quattro Real Time Quantitative Micro PCR Analyzer

Get a Price/Quote

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Truelab Quattro Real Time Quantitative Micro PCR Analyzer Price And Quantity

Minimum Order Quantity 1000 Piece

Product Description

Product details

Brand	Truelab
Cat. No.	623010001
Optics	Fluorescence, Three Wavelength
Principle	Patented real-time micro PCR
Size	248 mm x 185 mm x 112 mm
Speed	40 cycles of PCR/35 minutes

Advanced Multiplex Pathogen Detection

The Truelab Quattro Analyzer supports simultaneous processing of up to four samples, each running independently through its own detection channel. This capability is especially vital for busy hospital settings that require quick screening for multiple pathogens in diverse clinical samples. Accurate real-time quantification of viral and bacterial loads enhances diagnostic reliability.

Portable and User-Friendly Design

Weighing only 2.9 kg and constructed from sturdy ABS plastic, the Truelab Quattro is easy to transport and install in various healthcare environments. The intuitive 7-inch color touchscreen interface streamlines operation, making the device accessible to laboratory staff and field-deployable for remote testing applications.

Comprehensive Connectivity and Data Management

Integration with hospital information systems is seamless through USB, Wi-Fi, and LAN connectivity. The analyzer's large memory (8 GB, expandable) allows storage of over 10,000 test results, and data synchronization is facilitated with the Truelab Cloud, external PCs, or other machines, supporting efficient data sharing for timely clinical decisions.

FAQ's of Truelab Quattro Real Time Quantitative Micro PCR Analyzer:

Q: How do I operate the Truelab Quattro PCR Analyzer in a hospital or field setting?

A: To operate the analyzer, simply power it on using either AC mains or the built-in rechargeable battery. Load the prepared sample onto the Trueprep AUTO micro PCR chip, insert the chip, and follow the on-screen instructions via the touchscreen interface. The device is portable and requires minimal setup, making it suitable for both hospital labs and field deployments.

Q: What types of tests are supported by the Truelab Quattro, and can it handle multiple assays simultaneously?

A: The Truelab Quattro supports a wide range of real-time PCR assays for pathogens such as SARS-CoV-2, H1N1, TB, HIV, and more. It features four independent reaction channels, allowing you to run up to four different assays or samples at the same time, optimizing throughput and efficiency.

Q: When will I receive results after starting a test, and how are results displayed?

A: Each test typically takes between 30 and 60 minutes to complete. Results-including Ct values and quantitative measurements-are automatically analyzed and displayed on the 7-inch color touchscreen LCD. You can also review, export, or store results to the device's internal memory or transfer them via USB or Wi-Fi to external systems.

Q: Where can the Truelab Quattro be installed, and does it require specific environmental conditions?

A: The analyzer is designed for flexible installation in laboratories, clinics, and remote field locations. It operates efficiently at ambient temperatures between 15C and 35C and can be stored at temperatures ranging from -20C to 55C, ensuring functionality in a variety of environments.

Q: What is the sample volume required for each PCR test, and how are samples processed?

A: Each test uses a sample volume ranging from 5 to 50 L. Samples are prepared and loaded onto the Trueprep AUTO micro PCR chip, which is then inserted into the instrument. The automatic system streamlines the process, reducing hands-on time and potential error.

Q: How does the Truelab Quattro benefit laboratory workflows?

A: By offering rapid, multiplex detection of multiple pathogens with minimal user intervention, the analyzer increases laboratory throughput and diagnostic accuracy. Its portability, data management features, and automated operation simplify workflows and facilitate timely clinical decision-making.
