Biomerieux BACT/ALERT 3D

Get a Price/Quote

Product Details:

Material Polycarbonate/Powder-coated steel
Condition New
Technology Colorimetric detection of CO2 produced by microbial metabolism
Portable No
Disposable No
Wall Mounted No
Display Type LED status indicators; External PC (User interface)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Biomerieux BACT/ALERT 3D Price And Quantity

Incubation Temperature 35°C ± 1.0°C
Service Support Biomerieux technical support and maintenance
Capacity Up to 240 bottles (depending on configuration)
Bottles Supported FA Plus, PF Plus, FN Plus, SA, SN, and pediatric bottles
Modules Three module sizes: 40, 80, 240 bottle capacity
Interface Bidirectional interface with LIS
Operating Temperature 15-30°C (operating environment)
Alarms On-screen and audible alarms
Sample Types Blood, sterile body fluids, other clinical specimens
Time to Detection As early as a few hours, generally within 24 to 48 hours

Biomerieux BACT/ALERT 3D Product Specifications

Sensor Colorimetric sensor within culture bottles
Software Detail BACT/ALERT 3D management software
Wall Mounted No
Data Transmission Mode Ethernet/USB
Voltage 100240 V~ 50/60 Hz
Portable No
Real-Time Operation Yes
Disposable No
Attributes Continuous monitoring, modular design
Operating Type Automated incubation and detection system
Technology Colorimetric detection of CO2 produced by microbial metabolism
Material Polycarbonate/Powder-coated steel
Power Consumption Approx. 350 VA
Synchronize With Laboratory Information Systems (LIS)
Size Varies by module (e.g., 40-Bottle to 240-Bottle modules)
Color Gray/Blue
Usage Blood culture and other sterile body fluid culture detection
Power Source Main supply
Display Type LED status indicators; External PC (User interface)
Condition New
Internal Memory Managed by external PC software
Weight Varies by configuration (approx. 65300 kg)
Noise Level < 65 dB
Measurement Microbial growth detection in clinical samples

Incubation Temperature 35°C ± 1.0°C
Service Support Biomerieux technical support and maintenance
Capacity Up to 240 bottles (depending on configuration)
Bottles Supported FA Plus, PF Plus, FN Plus, SA, SN, and pediatric bottles
Modules Three module sizes: 40, 80, 240 bottle capacity
Interface Bidirectional interface with LIS
Operating Temperature 15-30°C (operating environment)
Alarms On-screen and audible alarms
Sample Types Blood, sterile body fluids, other clinical specimens
Time to Detection As early as a few hours, generally within 24 to 48 hours

Product Description

Brand Biomerieux

Model ALERT

Capacity 18 hours/ Test

CAT No 200290

Application Microbiology

The BACT/ALERTA 3D family of products brings you automated microbial detection systems with advantages in every dimension of blood culture testing from safety and design to recovery and accuracy. The systems provide optimal environments for the recovery of a wide range of microorganisms, including bacteria, fungi, and mycobacteria. BACT/ALERTA 3D offers all of this in a single innovative platform that is compact, modular, and flexible.

Advanced Detection Technology

The BACT/ALERT 3D system employs colorimetric detection of CO2, which is produced by microbial metabolism. This innovative technology allows for highly sensitive and specific detection of microbial growth directly within the culture bottles, supporting early intervention and rapid diagnosis. Continuous monitoring offers greater reliability and minimized downtime.

Flexible Capacity and Modular Design

With three module sizes-40, 80, and 240 bottle capacities-the BACT/ALERT 3D adapts to laboratories of varying throughput needs. Its modular construction means you can scale the system as your laboratory grows. Each unit operates quietly and efficiently, balancing high workload demands with minimal operational footprint.

Seamless Integration and User-Friendly Operation

This system offers bidirectional connectivity with Laboratory Information Systems (LIS) via Ethernet or USB, streamlining sample tracking and documentation. The external PC user interface, on-screen, and audible alarms ensure straightforward operation and rapid response to system alerts. The process is fully automated, leaving technicians free for other critical tasks.

FAQ's of Biomerieux BACT/ALERT 3D:

Q: How does the Biomerieux BACT/ALERT 3D detect microbial growth in clinical samples?

A: The system utilizes a colorimetric sensor within the culture bottles, detecting color changes caused by CO2 produced during microbial metabolism. This indicates the presence and growth of microorganisms in blood or other sterile body fluid samples.

Q: What types and capacities of bottles are compatible with the BACT/ALERT 3D instrument?

A: The BACT/ALERT 3D supports FA Plus, PF Plus, FN Plus, SA, SN, and pediatric bottles across three main module sizes: 40, 80, and 240 bottle capacity, providing flexibility for various laboratory requirements.

Q: When can I expect to receive results from the BACT/ALERT 3D system?

A: Detection of microbial growth may occur as early as a few hours, and most results are available within 24 to 48 hours, depending on the nature and load of the clinical specimen.

Q: Where is the BACT/ALERT 3D system typically used?

A: This instrument is widely utilized in clinical microbiology laboratories, hospitals, and diagnostic centers needing automated blood and sterile body fluid culture detection. Its scalability and integration capacity make it ideal for facilities of different sizes.

Q: What is the process for running a blood or body fluid culture on this system?

A: Specimens are inoculated into appropriate bottles, which are then placed into the system. The instrument continuously monitors each bottle for colorimetric changes, transmitting data to external PC software and alerting users to any positive detections via alarms.

Q: What are the key benefits of the BACT/ALERT 3D for laboratory operations?

A: The BACT/ALERT 3D delivers rapid, accurate detection with minimal manual intervention, continuous monitoring, and real-time alarms. Its modularity, automated functions, and LIS connectivity enhance laboratory efficiency, workflow, and diagnostic quality.

Q: How is technical support and maintenance managed for the BACT/ALERT 3D?

A: Biomerieux offers comprehensive technical support and maintenance services, ensuring optimal system performance and minimizing downtime for laboratories using the BACT/ALERT 3D.
