Thermo Fisher Scientific Invitrogen iBright CL750 Imaging System

Thermo Fisher Scientific Invitrogen iBright CL750 Imaging System

Get a Price/Quote

Product Details:

Classification Laboratory Instrument
Usage Protein and Nucleic Acid Gel Documentation
Operate Method Touchscreen Interface
Dimension (L*W*H) 350 mm 470 mm 480 mm
Application Western Blot, DNA/RNA Gel Imaging, Chemiluminescence, Fluorescence, Colorimetric analysis
Voltage 100-240 V
Capacity Up to 4 large blots per imaging session
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Thermo Fisher Scientific Invitrogen iBright CL750 Imaging System Price And Quantity

Thermo Fisher Scientific Invitrogen iBright CL750 Imaging System Product Specifications

Power 100-240 V AC, 50/60 Hz
Product Type Imaging System
Color White and Gray
Dimension (L*W*H) 350 mm 470 mm 480 mm
Application Western Blot, DNA/RNA Gel Imaging, Chemiluminescence, Fluorescence, Colorimetric analysis
Voltage 100-240 V
Capacity Up to 4 large blots per imaging session
Classification Laboratory Instrument
Usage Protein and Nucleic Acid Gel Documentation
Operate Method Touchscreen Interface
Material High-grade Plastic and Metal
Weight 27 kg

Touchscreen Display 12.1-inch high-definition multi-touch LCD
Dynamic Range 4.8 orders of magnitude
Detection Modes Chemiluminescence, Fluorescence, Colorimetric, Multi-channel
Data Storage Integrated SSD, supports external USB storage
Light Sources LED (Red, Green, Blue, UV)
Cooling System Peltier-based
Software iBright Analysis Software
Camera Resolution 9.1 megapixels CMOS
Operating System Embedded Linux
Safety Certifications CE, IEC/EN61010-1
Barcode Scanner Integrated for sample tracking
Environmental Requirements Temperature 1528C, Humidity 2080% RH
Connectivity USB, Ethernet, Wi-Fi
Image File Formats TIFF, JPEG, PNG
Exposure Time 0.1 seconds to 1 hour
Sample Tray Size 210 mm 170 mm

Product Description

Brand Thermo Fisher Scientific

Model CL750

Capacity 68 x 38 x 60 cm

CAT No A44116

Application Blotting

For expanded functionality, we also offer the more powerful iBright CL1500 Imaging System and iBright FL1500 Imaging System. The iBright CL1500 Imaging System supports the main imaging applications associated with chemiluminescent and colorimetric western blots, as well as fluorescent stained nucleic acid gels, fluorescent stained protein gels, colorimetric stained protein gels, and colorimetric membrane stains. The iBright FL1500 Imaging System features the same imaging capabilities as the iBright CL1500 Imaging System, but also offers fluorescent western blot imaging capability.

Efficient Multi-Mode Detection

The iBright CL750 supports diverse detection modes including chemiluminescence, fluorescence, and colorimetric analysis. It enables researchers to rapidly switch between modes, accommodating multiple experimental needs in one device. Its multi-channel detection provides high sensitivity for complex experiments.

Intuitive User Experience

Featuring a 12.1-inch high-definition multi-touch LCD, the iBright CL750 simplifies operation through an embedded Linux system and user-friendly iBright Analysis Software. Operation is streamlined, allowing users-from novice to expert-to easily capture and analyze high-quality images.

Versatile Connectivity and Storage

With built-in USB, Ethernet, Wi-Fi, and an integrated SSD for data storage, iBright CL750 makes image saving and sharing convenient. Users can also connect external devices via USB, facilitating effortless transfer and archiving of large datasets as needed.

FAQ's of Thermo Fisher Scientific Invitrogen iBright CL750 Imaging System:

Q: How does the iBright CL750 simplify the imaging process for Western Blots and nucleic acid gels?

A: The iBright CL750 automates imaging with a large 12.1-inch touchscreen, user-friendly software, and multi-channel detection. This integration allows easy setup, rapid exposure adjustment, and streamlined image capture in a single workflow.

Q: What types of detection modes can be used with the iBright CL750?

A: The system supports chemiluminescence, fluorescence, and colorimetric detection, as well as multi-channel imaging. This versatility accommodates several protocols, including protein and nucleic acid gel documentation, all in one instrument.

Q: When should I use the different LED light sources (Red, Green, Blue, UV)?

A: Choose the appropriate LED light source based on your assay's dye or staining agent. For example, UV excels with ethidium bromide, blue and green are ideal for SYBR and similar dyes, while red is suited for Cy5 or similar fluorophores.

Q: Where can data be stored or exported from the iBright CL750 Imaging System?

A: Images and data are saved to the integrated SSD within the system. For further convenience, files can be exported to external USB drives or over Ethernet and Wi-Fi connections to laboratory servers or cloud storage.

Q: What is the benefit of the integrated barcode scanner in laboratory workflows?

A: The barcode scanner streamlines sample tracking, helping avoid identification errors and ensuring data integrity throughout multi-sample, high-throughput imaging processes.

Q: How is temperature or humidity regulated during operation?

A: The iBright CL750 is designed to operate reliably within 15-28C and 20-80% relative humidity. It features a Peltier-based cooling system to maintain stable imaging conditions and optimal camera performance.

Q: What safety certifications does the iBright CL750 have for laboratory use in India?

A: The unit is certified with CE and IEC/EN61010-1 standards, demonstrating compliance with international safety requirements vital for laboratory safety in India and globally.
