Olympus CX33 Biological Microscope

Get a Price/Quote

Product Details:

Capacity Single Specimen Slide
Weight Approx. 6.0 kg
Classification Laboratory Equipment
Product Type Biological Microscope
Dimension (L*W*H) 236 mm x 397 mm x 383 mm
Power LED Illumination, approx. 3W
Color White & Black
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Olympus CX33 Biological Microscope Price And Quantity

Stage Mechanical Double Layer Stage 211 mm x 139 mm, X/Y Movement: 76 mm x 30 mm
Interpupillary Distance 4875 mm
Focus System Coaxial Coarse and Fine Focus, Focus Lock Mechanism
Dust Cover Included
Illumination Built-in LED with Long Life and Eco Mode
Optical System Infinity-Corrected Optical System (UIS2)
Condenser Abbe Condenser, N.A. 1.25 with Rack and Pinion Adjustment
Light Intensity Control Stepless/Continuous Control
Objective Lenses Revolving Quadruple Nosepiece (4x, 10x, 40x, 100x Oil Immersion)
Viewing Head Binocular, Inclined at 30, 360 Rotatable
Eyepiece Wide Field (FN 20, 10x) with Diopter Adjustment

Olympus CX33 Biological Microscope Product Specifications

Weight Approx. 6.0 kg
Capacity Single Specimen Slide
Dimension (L*W*H) 236 mm x 397 mm x 383 mm
Classification Laboratory Equipment
Product Type Biological Microscope
Power LED Illumination, approx. 3W
Material Metal Body with High-Grade Optical Components
Operate Method Manual Coarse & Fine Focus Adjustment
Voltage 100240 V, 50/60 Hz
Usage Microscopic Examination & Research
Application Clinical, Educational, Research Laboratories
Color White & Black

Stage Mechanical Double Layer Stage 211 mm x 139 mm, X/Y Movement: 76 mm x 30 mm
Interpupillary Distance 4875 mm
Focus System Coaxial Coarse and Fine Focus, Focus Lock Mechanism
Dust Cover Included
Illumination Built-in LED with Long Life and Eco Mode
Optical System Infinity-Corrected Optical System (UIS2)
Condenser Abbe Condenser, N.A. 1.25 with Rack and Pinion Adjustment
Light Intensity Control Stepless/Continuous Control
Objective Lenses Revolving Quadruple Nosepiece (4x, 10x, 40x, 100x Oil Immersion)
Viewing Head Binocular, Inclined at 30, 360 Rotatable
Eyepiece Wide Field (FN 20, 10x) with Diopter Adjustment

Product Description

Brand	Olympus
Model	CX33
Capacity	Trinocular Microscope
CAT No	CX33
Application	Microscopy

CX33 biological microscopes enable you to remain comfortable during long periods of routine observation. The microscope frame conforms to your hands, and the location of the control knobs maximizes ergonomics to improve work efficiency. With minimal movement, you can quickly set a specimen with one hand, while adjusting the focus and operating the stage with the other hand. The microscopes can also feature an optional camera port for digital imaging.

Advanced Optical Performance

Equipped with the UIS2 infinity-corrected optical system, the Olympus CX33 delivers superior image resolution and clarity essential for detailed specimen analysis. The microscope's quadruple nosepiece holds four objective lenses (4x, 10x, 40x, and 100x oil immersion), allowing users to easily switch magnification levels and obtain comprehensive visual data during research or clinical examinations.

Ergonomic and Durable Design

The CX33's metal construction ensures durability, while its binocular viewing head inclined at 30 and 360 rotatable design make extended observation comfortable. The interpupillary distance adjustment supports various users, and the mechanical double-layer stage offers precise X/Y movement, facilitating ease-of-use and accuracy in specimen handling for laboratories, educational institutions, and clinics alike.

Efficient and Eco-Friendly Illumination

The built-in LED illumination system of the CX33 offers consistent, bright lighting while operating efficiently at 3W. Its long-life LED, eco mode, and stepless light intensity control minimize power consumption and reduce eye strain over long observation periods. This makes the microscope ideal for routine laboratory work and extended research sessions.

FAQ's of Olympus CX33 Biological Microscope:

Q: How does the Olympus CX33 Biological Microscope enhance laboratory microscopy applications?

A: The CX33 combines advanced optical components, including infinity-corrected UIS2 optics and a quadruple nosepiece, to provide exceptional image quality and flexibility. Its ergonomic features and efficient LED illumination create a user-friendly setup suitable for clinical, educational, and research laboratories.

Q: What are the main benefits of the built-in LED illumination with eco mode?

A: The integrated LED light provides bright, consistent illumination for clear sample observation. The eco mode optimizes energy efficiency, reduces maintenance needs due to the long bulb life, and ensures comfortable viewing during extended use.

Q: When is oil immersion (100x) objective used, and what is its advantage?

A: Oil immersion (100x) objective is typically used when maximum magnification and resolution are required, such as in detailed cellular or microbial studies. The oil enhances light transmission, resulting in sharper and more detailed images.

Q: Where can the Olympus CX33 Biological Microscope be applied?

A: This microscope is ideal for use in clinical, educational, and research laboratories. Its versatile features suit various microscopic examination and research tasks in hospitals, universities, schools, research institutes, and diagnostic centers.

Q: What is the process for adjusting specimen focus on the CX33?

A: The CX33 features coaxial coarse and fine focus knobs and a focus lock mechanism. Users start with coarse adjustment for basic image clarity, then proceed with the fine focus for precise detailing. The focus lock helps preserve settings and prevent damage to slides when switching specimens.

Q: How does the mechanical double-layer stage improve specimen handling?

A: The stage, measuring 211 mm x 139 mm with 76 mm x 30 mm X/Y movement, allows smooth and accurate positioning of slides. Its dual-layer design enables precise control over movement, critical in scanning specimens or aligning features of interest for extended analysis.
