Thermo Fisher Scientific Invitrogen Luminex 200 Instrument System

Thermo Fisher Scientific Invitrogen Luminex 200 Instrument System

Get a Price/Quote

Product Details:

Voltage 100-240 V AC, 50/60 Hz
Color White/Grey
Capacity Up to 100 analytes per sample
Dimension (L*W*H) 46.7 x 37.5 x 42.2 cm
Classification Laboratory Analytical Instrument
Material High-Grade Industrial Plastic and Metal Housing
Power 180 VA
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Thermo Fisher Scientific Invitrogen Luminex 200 Instrument System Price And Quantity

Throughput Up to 96-well plate/45 minutes (per plate)
Sample Formats 96-well or 384-well plate compatible
Environment 1030C operating temperature, 2080% non-condensing humidity
Barcode Reader Integrated plate/barcode reader (optional)
Calibration Automated with Luminex system calibration and verification kits
Optical System Dual lasers (635 nm and 532 nm), photomultiplier tube for detection
Communication Interface USB and Ethernet connectivity
Sample Volume Required Minimum 50 L
Software Features Multiplexing analysis, customizable protocol setup, secure data management
Data Output CSV, XLS, PDF formats supported
Maintenance Automated fluidics cleaning and maintenance protocols
Compliance CE and IVD certified, meets ISO/IEC standards
Detection Sensitivity As low as 3.2 pg/mL
Dynamic Range 3.5 logs

Thermo Fisher Scientific Invitrogen Luminex 200 Instrument System Product Specifications

Usage Quantitative detection of multiple analytes in a single sample
Weight 27 kg
Product Type Multiplexing Flow-based Detection Instrument
Operate Method PC-based with xPONENT software control
Application Proteomics, Genomics, Biomarker Discovery, Immunoassays, Multiplex Assays
Power 180 VA
Material High-Grade Industrial Plastic and Metal Housing
Classification Laboratory Analytical Instrument
Dimension (L*W*H) 46.7 x 37.5 x 42.2 cm
Capacity Up to 100 analytes per sample
Color White/Grey
Voltage 100-240 V AC, 50/60 Hz

Throughput Up to 96-well plate/45 minutes (per plate)
Sample Formats 96-well or 384-well plate compatible
Environment 1030C operating temperature, 2080% non-condensing humidity
Barcode Reader Integrated plate/barcode reader (optional)
Calibration Automated with Luminex system calibration and verification kits
Optical System Dual lasers (635 nm and 532 nm), photomultiplier tube for detection
Communication Interface USB and Ethernet connectivity
Sample Volume Required Minimum 50 L
Software Features Multiplexing analysis, customizable protocol setup, secure data management
Data Output CSV, XLS, PDF formats supported
Maintenance Automated fluidics cleaning and maintenance protocols
Compliance CE and IVD certified, meets ISO/IEC standards
Detection Sensitivity As low as 3.2 pg/mL
Dynamic Range 3.5 logs

Product Description

Brand Thermo Fisher Scientific

Model Luminex 200

Capacity Up to 100 Tests per Hour

CAT No APX10031

Application Flow Cytometry

The Luminex 200 Instrument System sets the standard for multiplexing, providing the ability to perform up to 100 different tests in a single reaction volume on a flow cytometry-based platform. The Luminex 200 system is compatible with ProcartaPlex multiplex immunoassays and QuantiGene Plex multiplex gene expression assays.

Dual-Laser Optical Performance

The Invitrogen Luminex 200 features an advanced dual-laser configuration (635 nm and 532 nm) with a high-sensitivity photomultiplier tube. This ensures precise multiplex analysis and robust signal detection across a dynamic range of 3.5 logs, providing reliable results even at low analyte concentrations.

Streamlined Workflow and Throughput

Optimize laboratory productivity with automated fluidics cleaning, maintenance protocols, and rapid processing-reaching up to a 96-well plate in 45 minutes. The system supports both 96- and 384-well plate formats, making it ideal for high-throughput screening and assay flexibility in diverse research applications.

User-Friendly Interface and Secure Data Management

The Luminex 200 is operated via secure, PC-based xPONENT software that allows customizable protocol setups, comprehensive multiplexing analysis, and flexible, secure data exports (CSV, XLS, PDF). Optional integrated barcode reader streamlines sample tracking and ensures traceability for regulatory compliance.

FAQ's of Thermo Fisher Scientific Invitrogen Luminex 200 Instrument System:

Q: How does the Luminex 200 Instrument System perform multiplex analyte detection?

A: The Luminex 200 utilizes dual lasers and bead-based immunoassay technology to detect up to 100 different analytes per sample simultaneously. The multiplexing process ensures distinct identification and quantification of proteins, nucleic acids, or biomarkers in a single reaction, substantially increasing lab efficiency.

Q: What is the minimum sample volume required for analysis on this instrument?

A: The Luminex 200 requires a minimum sample volume of 50 L, allowing researchers to conserve valuable samples while maintaining accurate detection across a broad dynamic range.

Q: When should the Luminex 200 be calibrated, and is the process automated?

A: Calibration of the instrument is recommended as per the manufacturer's guidelines or before critical assays. The system features automated calibration and verification using specialized Luminex kits, ensuring consistent accuracy and compliance with CE, IVD, and ISO/IEC standards.

Q: Where can I use the Luminex 200 Instrument System?

A: Designed for laboratories across proteomics, genomics, biomarker discovery, and immunoassay applications, the Luminex 200 can be deployed in research institutions, diagnostic labs, and clinical environments where precise multiplexed measurements are essential.

Q: What data output formats are supported, and how can I access the results?

A: After analysis, results can be exported in CSV, XLS, or PDF formats, offering compatibility with data analysis and reporting workflows. The instrument is controlled via PC with xPONENT software, and supports both USB and Ethernet connectivity for seamless data transfer.

Q: How does automated maintenance benefit laboratory operation?

A: Automated fluidics cleaning and maintenance protocols reduce manual intervention, minimize instrument downtime, and help prolong the lifespan of the system, making routine use easier and more reliable for busy labs.
