Qiagen NeuMoDx 96 Molecular System

Get a Price/Quote

Product Details:

Material Powder-coated Steel, ABS
Condition New
Technology Real-Time PCR
Portable No
Disposable No
Wall Mounted No
Light Source LED
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Qiagen NeuMoDx 96 Molecular System Price And Quantity

Qiagen NeuMoDx 96 Molecular System Product Specifications

Internal Memory 500 GB HDD
Sensor Fluorescence Detection Sensor
Software Detail Qiagen NeuMoDx Software Suite
Power Consumption 600 VA max.
Size 103 x 79 x 76 cm
Light Integrated Fluorescence Excitation
Technology Real-Time PCR
Resolution 1280 x 800 pixels
Material Powder-coated Steel, ABS
Condition New
Synchronize With LIS (Laboratory Information System) Compatible
Weight ~220 kg
Operating Type Automated
Attributes Fully automated, random-access, true sample-to-result processing
Voltage 100-240V AC, 50/60Hz
Wall Mounted No
Disposable No
Usage High-throughput molecular diagnostics
Light Source LED
Noise Level <70 dB
Real-Time Operation Yes
Color White/Gray
Power Source Mains Electricity
Measurement Qualitative and Quantitative Nucleic Acid
Data Transmission Mode USB, Ethernet
Portable No
Display Type Touchscreen LCD

Product Description

Brand Qiagen

Model NeuMoDx

Capacity 96 Wells

CAT No 500200

Application Molecular Biology

NeuMoDx Molecular Systems combine automated nucleic acid extraction, amplification and detection on a single instrument. The NeuMoDx instruments are the industryas first true random-access system that are scalable according to the needs of your laboratory. The flexibility of the system allows the consolidation of your infectious disease portfolio onto one system.

True Sample-to-Result Automation

The NeuMoDx 96 offers a fully automated workflow, from sample loading to results reporting, minimizing manual intervention. Its random-access design enables laboratories to load samples and reagents without interrupting ongoing processes, ensuring continuous workflow and higher productivity in demanding diagnostic environments.

Versatile Multiplexing and Sample Compatibility

Capable of processing a diverse range of biological samples, the NeuMoDx 96 delivers reliable outcomes even with challenging matrices. Its multiplexing capability allows simultaneous detection of up to four nucleic acid targets in a single reaction, optimizing assay throughput and resource efficiency.

Seamless Laboratory Integration

Equipped with a touchscreen LCD, barcode scanner, and robust software suite, the system integrates easily with Laboratory Information Systems (LIS). This enhances data management and traceability, supporting stringent laboratory standards and seamless connectivity for comprehensive workflow management.

FAQ's of Qiagen NeuMoDx 96 Molecular System:

Q: How does the Qiagen NeuMoDx 96 Molecular System ensure fully automated and efficient sample processing?

A: The NeuMoDx 96 uses advanced robotics for automated sample handling, onboard reagent refrigeration, and integrated barcode scanning. Its continuous random-access capability allows new samples or reagents to be loaded at any time, optimizing workflow efficiency and minimizing hands-on time.

Q: What types of samples can the NeuMoDx 96 Molecular System process and how does this benefit laboratories?

A: This system is designed to handle a wide variety of biological samples-including plasma, serum, urine, swabs, and other general biological specimens. This versatility streamlines operations by enabling multiple assay types on a single platform, reducing the need for multiple instruments.

Q: When should the reagents and instrument be stored at different temperatures?

A: The NeuMoDx 96 instrument should be kept at 15C to 30C, while reagents are stored at 2C to 8C to maintain stability and performance. Automated onboard refrigeration ensures reagents stay at the optimal temperature during operation.

Q: Where can the NeuMoDx 96 system be installed within a laboratory?

A: Ideally, the system should be placed in a controlled laboratory environment with ambient temperatures between 18C and 30C and relative humidity of 20% to 80%. Its size and weight require a sturdy, dedicated workspace with access to mains electricity.

Q: What is the process for running a molecular test on the NeuMoDx 96?

A: After loading the appropriate samples and reagents, the user selects or programs the desired assay using the touchscreen interface. The system then performs automated nucleic acid extraction, real-time PCR amplification, fluorescence-based detection, and data analysis, delivering results within 60-120 minutes.

Q: How does multiplexing in the NeuMoDx 96 enhance laboratory throughput?

A: Its multiplexing capability allows up to four distinct targets to be analyzed in a single reaction. This means laboratories can simultaneously detect multiple pathogens or genetic markers in one run, conserving reagents and reducing turnaround time.

Q: What benefits does LIS connectivity provide when using the NeuMoDx 96 Molecular System?

A: LIS (Laboratory Information System) connectivity streamlines sample tracking, result reporting, and data management. This integration reduces manual entry errors, supports regulatory compliance, and facilitates faster communication of test results within the clinical workflow.
