Boditech AFIAS HbA1c

Get a Price/Quote

Product Details:

Shelf Life 18 Months (Kit)
Storage Instructions Store at 28C
Accuracy Highly sensitive, comparable to HPLC methods
Frequency 50/60 Hz
Measurement Range 4.015.0 % HbA1c
Instruments Type Clinical Laboratory Analyzer
Function Measures Glycated Hemoglobin
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Boditech AFIAS HbA1c Price And Quantity

Maintenance Minimal required
Target Users Hospitals, Laboratories, Clinics
Result Time 3 minutes per test
Humidity Range 1080% RH (non-condensing)
User Interface Touch buttons
Calibration Factory pre-calibrated
Test Principle Immunoassay method using fluorescence
Operating Temperature 1030C
Data Output USB, RS-232C
Sample Volume 5 L whole blood
Package Contents AFIAS Analyzer, Power Adapter, User Manual

Boditech AFIAS HbA1c Product Specifications

Color White
Condition New
Usage Type Clinical Diagnostic
Material ABS Plastic, Metal Components
Display Type LCD
Function Measures Glycated Hemoglobin
Operating Type Automatic
Instruments Type Clinical Laboratory Analyzer
Features Compact size, easy-to-use interface, fast results in 3 minutes
Measurement Range 4.015.0 % HbA1c
Frequency 50/60 Hz
Noise Level Low
Dimension (L*W*H) 188 mm x 147 mm x 55 mm
Voltage 100240 V, 50/60 Hz
Technology Fluorescence Immunoassay
Wall Mounted No
Accuracy Highly sensitive, comparable to HPLC methods
Power Source AC Adapter
Real-Time Operation Yes
Equipment Type Automatic Immunoassay Analyzer
Power Consumption 20 VA
Shelf Life 18 Months (Kit)
Storage Instructions Store at 28C
Weight 1.58 kg
Portable Yes
Use For quantitative determination of HbA1c in human whole blood

Maintenance Minimal required
Target Users Hospitals, Laboratories, Clinics
Result Time 3 minutes per test
Humidity Range 1080% RH (non-condensing)
User Interface Touch buttons
Calibration Factory pre-calibrated
Test Principle Immunoassay method using fluorescence
Operating Temperature 1030C
Data Output USB, RS-232C
Sample Volume 5 L whole blood
Package Contents AFIAS Analyzer, Power Adapter, User Manual

Product Description

Brand Boditech

Sample Type Serum/ Plasma/ WB

Pack Size 24T

CAT No SMFP-28

Biomarker Diabetes

This test is certified by NGSP (National Glycohemoglobin Standardization Program). It helps diabetic diagnosis, treatment, and prognosis by measuring the glycated hemoglobin concentration (%) in a small amount of blood over the past 3 months.

Fast and Accurate HbA1c Testing

Experience reliable HbA1c measurement with the Boditech AFIAS analyzer, which utilizes cutting-edge fluorescence immunoassay technology. Each test requires only a 5 L whole blood sample and provides results in just 3 minutes, enabling prompt clinical decision-making. Factory pre-calibration ensures consistent accuracy, making it highly suitable for busy healthcare environments.

User-Friendly and Portable Design

The AFIAS HbA1c analyzer features an LCD screen and intuitive touch-button interface, ensuring ease of operation for all users. Its compact build (188 mm x 147 mm x 55 mm) and lightweight structure (1.58 kg) support excellent portability between workstations. The analyzer's minimal maintenance needs and low noise operation further enhance convenience.

Comprehensive Package and Connectivity

Each package includes the AFIAS analyzer, power adapter, and user manual. With versatile data output options (USB, RS-232C), it seamlessly integrates with existing laboratory systems. Operating between 10-30C with up to 80% relative humidity (non-condensing), the device is well-suited for clinics, hospitals, and laboratories.

FAQ's of Boditech AFIAS HbA1c:

Q: How does the Boditech AFIAS HbA1c analyzer measure glycated hemoglobin?

A: The AFIAS HbA1c analyzer operates using a fluorescence immunoassay method, ensuring precise and highly sensitive quantification of HbA1c in whole blood samples.

Q: What is the sample volume required and result turnaround time for each test?

A: Only 5 L of whole blood is needed per test, and results are available within 3 minutes, allowing swift patient management.

Q: When is calibration required for the AFIAS HbA1c device?

A: No user calibration is necessary. The device comes pre-calibrated from the factory, guaranteeing reliable performance and saving operational time.

Q: Where can the AFIAS HbA1c analyzer be used?

A: Designed for use in hospitals, laboratories, and clinics, the device is also portable and can be easily relocated as needed within healthcare facilities.

Q: What is the process for storing and maintaining the HbA1c testing kit?

A: Test kits should be stored at temperatures between 2-8C, and the analyzer requires only minimal maintenance, making it straightforward to manage on a daily basis.

Q: How does the analyzer integrate with lab information systems?

A: Results can be exported via USB or RS-232C interfaces, allowing efficient data transfer and seamless integration into various laboratory workflow systems.
