BioRad CFX Opus 384 Real-Time PCR System

Get a Price/Quote

Product Details:

Material High-grade plastics and metal alloys
Condition New
Technology Real-Time PCR Technology
Portable No (Benchtop instrument)
Disposable No
Wall Mounted No
Light Source Solid-state LEDs
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

BioRad CFX Opus 384 Real-Time PCR System Price And Quantity

Cooling System Peltier-based
Operating Temperature 15C30C (ambient)
Supported Plate Types Standard 384-well PCR plates
Humidity Range 20%80% (non-condensing)
Run Time 20 min to several hours (protocol dependent)
Temperature Range 4C100C
Safety Certifications CE, CTUVus
Maximum Sample Capacity 384 reactions/run
Excitation Wavelengths Multiple (per respective channel)
Service & Warranty Standard 1-year warranty; extended options available
Detection Channels 5 fluorescent channels
Temperature Uniformity 0.4C
Connectivity USB, Ethernet
Remote Monitoring Available via CFX Maestro software
Calibration Automatic optical and thermal calibration
Ramp Rate Up to 5C/sec
Thermal Block Format 384-well

BioRad CFX Opus 384 Real-Time PCR System Product Specifications

Real-Time Operation Yes
Power Consumption Max 600 W
Disposable No
Light Solid-state LED
Technology Real-Time PCR Technology
Noise Level < 60 dB(A)
Power Source AC mains
Material High-grade plastics and metal alloys
Sensor Photodiode for fluorescence detection
Wall Mounted No
Operating Type Automated
Condition New
Usage High-throughput quantitative PCR applications
Internal Memory Integrated; for onboard data storage and processing
Software Detail CFX Maestro Software (data acquisition, analysis, export)
Weight 31 kg
Size W 39 cm D 52 cm H 39 cm
Portable No (Benchtop instrument)
Measurement Quantitative PCR detection
Light Source Solid-state LEDs
Data Transmission Mode USB, Ethernet
Resolution Optical detection: 384 wells
Attributes High uniformity; advanced temperature control
Voltage 100240 V AC, 5060 Hz
Color Green
Battery No (AC powered)
Display Type Digital
Synchronize With CFX Maestro software/computer

Cooling System Peltier-based
Operating Temperature 15C30C (ambient)
Supported Plate Types Standard 384-well PCR plates
Humidity Range 20%80% (non-condensing)
Run Time 20 min to several hours (protocol dependent)
Temperature Range 4C100C
Safety Certifications CE, CTUVus
Maximum Sample Capacity 384 reactions/run
Excitation Wavelengths Multiple (per respective channel)
Service & Warranty Standard 1-year warranty; extended options available
Detection Channels 5 fluorescent channels
Temperature Uniformity 0.4C
Connectivity USB, Ethernet
Remote Monitoring Available via CFX Maestro software
Calibration Automatic optical and thermal calibration
Ramp Rate Up to 5C/sec
Thermal Block Format 384-well

Product Description

Brand	BioRad
Model	CFX Opus 384
Capacity	384 Wells
CAT No	12011452
Application	Molecular Biology

CFX Opus is the newest real-time PCR system in our robust CFX Family. The CFX Opus 384 Real-Time PCR System can analyze 384 wells and offers a number of new features like more uniform thermal performance, expanded connectivity Wi-Fi, ethernet, and USB. Cloud connectivity: Operate CFX Opus on our BR.io cloud platform or with desktop CFX Maestro Software, Network storage drive access for excellent data management and Shuttle optical system yields consistent optical measurements across your sample plate.

High-Throughput Multiplexing for Modern Labs

The CFX Opus 384 enables simultaneous quantification of up to 384 reactions, dramatically accelerating workflows in genomics, diagnostics, and life science research. Its multi-channel fluorescence detection allows efficient multiplexing, making it indispensable for high-demand settings seeking both speed and accuracy.

Precision Temperature Control and Calibration

The thermal block system ensures uniform heating and cooling across all wells, with a precise temperature range between 4C and 100C and uniformity of 0.4C. Automatic optical and thermal calibration minimize manual intervention, guaranteeing consistent, reproducible results for every run.

Seamless Integration and Remote Monitoring

With USB and Ethernet connectivity, the system integrates easily into existing lab environments. The included CFX Maestro software enables real-time data access and remote monitoring, allowing users to manage runs and analyze data from virtually any location with network access.

FAQ's of BioRad CFX Opus 384 Real-Time PCR System:

Q: How does the CFX Opus 384 improve qPCR efficiency in high-throughput labs?

A: By supporting up to 384-well plates and offering rapid ramp rates (up to 5C/sec), the CFX Opus 384 significantly reduces experiment time and increases sample capacity, making it ideal for processing large sample volumes quickly and accurately.

Q: What types of samples or applications can be run on this PCR system?

A: The system is designed for various quantitative PCR (qPCR) applications, including gene expression analysis, genotyping, pathogen detection, and mutation analysis, using standard 384-well PCR plates for high sample throughput.

Q: When should automatic calibration be performed, and how is it managed?

A: Automatic optical and thermal calibration occur routinely during operation or after system software prompts. This feature helps ensure measurement accuracy and consistency without frequent manual intervention.

Q: Where can remote monitoring and data analysis be accessed?

A: Remote monitoring and data analysis are performed via CFX Maestro software, which can be installed on a networked computer, enabling users to access experiment progress and results from within the facility or remotely.

Q: What benefits does the advanced temperature uniformity provide for users?

A: With a block uniformity of 0.4C, the system ensures each well experiences the same thermal conditions, significantly improving data reproducibility and experiment reliability, which is crucial for sensitive quantitative PCR assays.

Q: How is data stored and exported from the BioRad CFX Opus 384 system?

A: The instrument features integrated onboard memory for data storage and supports data export through USB or Ethernet connections, facilitating straightforward data management and analysis across different platforms.
