QuantStudio 5 Real Time PCR System 96-well

Get a Price/Quote

Product Details:

Material Plastic
Condition New
Technology qPCR (Real-Time PCR)
Portable No
Disposable No
Wall Mounted No
Light Source High-brightness LED
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

QuantStudio 5 Real Time PCR System 96-well Product Specifications

Power Consumption 700 W max
Weight 21 kg
Color White
Synchronize With Cloud connectivity (Thermo Fisher Cloud)
Disposable No
Usage Laboratory Real-Time PCR assays
Software Detail QuantStudio Design and Analysis software
Sensor Photodiode
Internal Memory 128 GB SSD
Measurement Quantification, melting curve analysis, genotyping, presence/absence
Wall Mounted No
Power Source Electric
Noise Level <70 dB
Condition New
Attributes User-friendly software, high detection sensitivity, multiplexing capability
Technology qPCR (Real-Time PCR)
Real-Time Operation Yes
Size 27 x 50 x 40 cm (W x D x H)
Resolution 96-well x 0.1 mL block, 21.5 1920 x 1080 touchscreen
Portable No
Data Transmission Mode Ethernet, USB, Wi-Fi
Operating Type Touchscreen control
Light LED
Display Type LCD Display
Light Source High-brightness LED
Voltage 100240 V, 50/60 Hz, 700 W max
Material Plastic

Temperature Uniformity ±0.25°C
Ramp Rate 3.0°C/sec max
Connectivity USB, LAN, Wi-Fi
Capacity 96 x 0.1 mL tubes or strip
Temperature Accuracy ±0.25°C
Supported Dyes FAM/SYBR Green, VIC/HEX/JOE, ROX/Texas Red, Cy5/LIZ, TAMRA, NED
Operating Temperature Range 15°C to 30°C
Excitation/Emission Filters 6 excitation/6 emission filters
Compliance IVD, CE
Block Format 96-well, 0.1 mL

Product Description

Product Details:

Model Name/Number	QuantStudio 5
Includes	Desktop
Brand	Thermofisher
Sample Capacity/Format	96/384 Wells
Volume Thermal Block Sample	0.2ml
Temperature Accuracy	0.25 Degree Celsius
Maximum Ramp Rate	6.5 Degree Celsius/s
Average Ramp Rate	3.66 Degree Celsius/s
Shipping Condition	Room Temperature
Block Format	Non-Interchangeable
Display Type	Touch Screen
Smaller foot print	27x50x40 cm

Features:

Proven OptiFlex technology (6 decoupled channels/21 filter combinations with white LED) for trusted results
User account management, locked workflow, and Pause features for greater control of experiment data
Built-in software features to support compliance with 21 CFR Part 11 guidelines
Secure cloud-based software provides increased accessibility and storage options
Simplified instrument software with interactive touchscreen for greater ease of use

The Applied Biosystems QuantStudio 5 Real-Time PCR System for Human Identification with tower computer is the latest addition to our human identification (HID) real-time PCR family of products. This instrument is designed for both new and experienced users who need a simple, reliable, and affordable real-time PCR system that doesnt require compromise on performance or quality. When used with our latest advances in quantification chemistry and HID Real-Time PCR Analysis Software, this system offers a sensitive, robust solution for forensic DNA quantification. It also helps prepare laboratories for future quantification technologies. With maximum dye versatility, this HID solution offers accurate, trusted results in a small benchtop footprint.

Advanced Temperature Control for Accurate Results

With temperature uniformity and accuracy set at 0.25C, the QuantStudio 5 ensures consistent and reliable amplification results across all wells. This high-level performance is essential for applications where precision is critical, such as genotyping, quantification, and presence/absence testing. Its advanced thermal block technology enables reproducible data in every run, making it an invaluable asset in research and clinical laboratories alike.

Multiplexing Capability and Flexible Dye Support

The system features six excitation and six emission filters, allowing simultaneous detection of multiple fluorescent dyes including FAM, VIC, HEX, ROX, Cy5, TAMRA, and more. This multiplexing capability enables efficient, cost-effective analysis by accommodating various assays in a single run, significantly enhancing laboratory throughput and data quality.

User-Friendly Design and Smart Connectivity

Equipped with a 21.5" high-definition touchscreen and intuitive QuantStudio Design and Analysis software, the system simplifies protocol setup and data analysis. Multiple connectivity options-including USB, LAN, and Wi-Fi-synchronize data with other machines and Thermo Fisher Cloud, facilitating seamless integration into laboratory workflows for efficient data sharing and remote management.

FAQ's of QuantStudio 5 Real Time PCR System 96-well:

Q: How do I operate the QuantStudio 5 Real Time PCR System?

A: The QuantStudio 5 PCR system is controlled via an intuitive 21.5" LCD touchscreen and user-friendly QuantStudio software. Protocol setup, assay selection, and real-time monitoring are streamlined, making the device suitable for both novice and experienced users in laboratory environments.

Q: What sample formats are compatible with this instrument?

A: This system is designed to accommodate 96 x 0.1 mL tubes or strips, providing flexibility for a range of PCR assay setups. Its universal block format suits various standard and specialized laboratory applications.

Q: When should I use multiplexing with this system?

A: Multiplexing is ideal when you want to detect multiple targets in a single reaction to save time, reagents, and sample material. The QuantStudio 5 supports several dye channels, enabling efficient multiplex assays without compromising sensitivity or specificity.

Q: Where can I access or analyze my PCR data after a run?

A: Data can be retrieved through USB, Ethernet, LAN, or Wi-Fi. Additionally, the instrument connects with Thermo Fisher Cloud, enabling remote data access, secure sharing, and further analysis from any connected device.

Q: What benefits does the system's thermal accuracy provide?

A: Maintaining a thermal uniformity and accuracy of 0.25C ensures every well experiences nearly identical conditions, boosting reproducibility and accuracy in quantification, genotyping, and melting curve assays.

Q: How does the QuantStudio 5 benefit high-throughput labs?

A: Its capacity for 96 samples per run, high detection sensitivity, robust multiplexing, and streamlined connectivity make it perfect for laboratories requiring efficient workflow, rapid turnaround, and consistent high-quality results.
