Mindray Chemistry Analyzer BS-480

Get a Price/Quote

Product Details:

Material High-quality ABS/plastic and metal components
Condition Brand New
Technology Discrete, Random Access, Fully Automated
Portable No
Disposable No
Wall Mounted No
Light Source Halogen lamp, 12V/15W with long lifespan
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Mindray Chemistry Analyzer BS-480 Price And Quantity

Reagent Positions 80 refrigerated reagent positions
Wavelengths 13 wavelengths (340-800 nm) selection
Calibration Method Linear, nonlinear, multi-point
Carryover Rate <0.05% (for most items)
Stat Sample STAT sample priority available
Interface Bi-directional, LIS/HIS compatible
Reaction Cuvettes Reusable, 80 positions (rotary type)
Sample Loading Up to 100 samples, Continuous loading
Incubation 37C controlled
Automatic Sample Dilution Yes
Bar Code Reader Supported (Optional)
Sample Type Serum, Plasma, Urine, CSF
Water Consumption 8L/h
Sample Volume 2 - 45 L
Throughput Up to 400 tests/hour (photometric), up to 560 tests/hour with ISE
Environmental Conditions Temperature: 15-30C, Humidity: 35-85%

Mindray Chemistry Analyzer BS-480 Product Specifications

Noise Level Less than 60 dB
Synchronize With Laboratory Information System (LIS)
Portable No
Display Type 10.4-inch TFT Touch Screen
Resolution 800 x 600 pixels
Size 1290 mm x 930 mm x 690 mm (WxDxH)
Battery Not Applicable (Mains-powered)
Sensor Photometric, ISE modules (optional)
Light Halogen lamp integrated
Power Source Electric; AC Mains
Disposable No
Weight 180 kg
Material High-quality ABS/plastic and metal components
Real-Time Operation Yes, Automated Real-Time Operation
Data Transmission Mode RS232, USB, LAN, LIS-compatible
Light Source Halogen lamp, 12V/15W with long lifespan
Color White / Gray combination
Technology Discrete, Random Access, Fully Automated
Condition Brand New
Measurement Chemistry, Immunoturbidimetric tests
Power Consumption Less than 1,000 VA
Attributes High throughput, random access, continuous loading, user-friendly
Usage Clinical Chemistry analysis in laboratories
Internal Memory Sufficient for 100,000 patient results
Voltage AC 100-240V, 50/60Hz
Software Detail User-friendly software with LIS connectivity
Wall Mounted No
Operating Type Full Automated Operation

Reagent Positions 80 refrigerated reagent positions
Wavelengths 13 wavelengths (340-800 nm) selection
Calibration Method Linear, nonlinear, multi-point
Carryover Rate <0.05% (for most items)
Stat Sample STAT sample priority available
Interface Bi-directional, LIS/HIS compatible
Reaction Cuvettes Reusable, 80 positions (rotary type)
Sample Loading Up to 100 samples, Continuous loading
Incubation 37C controlled
Automatic Sample Dilution Yes
Bar Code Reader Supported (Optional)
Sample Type Serum, Plasma, Urine, CSF
Water Consumption 8L/h
Sample Volume 2 - 45 L
Throughput Up to 400 tests/hour (photometric), up to 560 tests/hour with ISE
Environmental Conditions Temperature: 15-30C, Humidity: 35-85%

Product Description

Brand	Mindray
Model	BS-480
Capacity	200 Test/Hr
CAT No	BS-480
Application	Biochemistry

A floor-standing, discrete and random access clinical chemistry analyzer offering constant throughput of 400 tests per hour.

High Throughput and Versatility

The BS-480 delivers up to 400 photometric tests per hour, with increased capacity utilizing the optional ISE module, reaching 560 tests per hour. With its random access technology, the analyzer adapts to different test requirements and handles varied sample types including serum, plasma, urine, and CSF. Its robust design makes it ideal for clinical laboratories seeking flexibility and productivity.

User-Friendly Automated Operation

Equipped with a large, 10.4-inch TFT touch screen and intuitive software, the BS-480 ensures seamless workflow management. The automated, real-time operational capabilities enable users to continuously load samples, minimizing downtime and optimizing efficiency. LIS compatibility allows for easy data integration, making result management straightforward and more organized.

Advanced Sample and Reagent Handling

Featuring 80 refrigerated reagent positions and automatic sample dilution, the analyzer guarantees accuracy and stability. Up to 100 samples can be continuously loaded onto the system, while the STAT sample function allows for urgent tests to be processed with priority. Its advanced design and reliable sensors ensure precision in every step of the testing process.

FAQ's of Mindray Chemistry Analyzer BS-480:

Q: How does the Mindray BS-480 ensure high throughput in laboratory settings?

A: The BS-480 achieves high throughput with the ability to process up to 400 tests per hour photometrically, which can be extended to 560 tests per hour using the optional ISE module. This efficiency is further enhanced by random access technology and continuous loading capabilities for up to 100 samples at a time.

Q: What types of samples can be analyzed with the BS-480, and where is it typically used?

A: The analyzer supports serum, plasma, urine, and CSF samples, commonly used in clinical laboratories for routine chemistry and immunoturbidimetric tests. It is ideal for environments where versatility and reliability are critical, such as hospitals, diagnostic centers, and research institutions.

Q: When is STAT sample processing available, and how does it benefit workflow?

A: STAT sample processing can be initiated whenever urgent results are needed. This function prioritizes targeted samples, ensuring fast turnaround for critical cases, thus enhancing patient care and laboratory efficiency.

Q: What are the advantages of the BS-480's reusable cuvette system and reagent positions?

A: The 80-position rotary cuvette system is reusable, reducing operational costs and environmental waste. The analyzer also features 80 refrigerated reagent positions to maintain stability and accuracy, even during high-frequency testing, ensuring consistent results.

Q: How is sample loading and dilution managed on the BS-480?

A: Continuous sample loading allows operators to add samples without interrupting the testing process. The system also provides automatic sample dilution and a very low carryover rate of less than 0.05% for most items, enhancing data integrity and operational convenience.

Q: What makes the BS-480's software and interface suitable for modern labs?

A: The user-friendly software supports LIS/HIS connectivity and accommodates data transmission via RS232, USB, and LAN. With a 10.4-inch TFT touch screen and sufficient memory for 100,000 patient results, it streamlines workflow and records management, making it easy for labs to handle high test volumes.
