Qiagen QIAxcel Connect

Get a Price/Quote

Product Details:

Material Robust plastic housing with electronic components
Condition Brand New
Technology Capillary electrophoresis system for nucleic acid separation
Portable No
Disposable No
Wall Mounted No
Light Source LED
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Qiagen QIAxcel Connect Price And Quantity

Qiagen QIAxcel Connect Product Specifications

Synchronize With QIAxcel ScreenGel software on PC
Size 47 x 47 x 36 cm (L x W x H)
Power Source AC Power
Light LED-based detection
Material Robust plastic housing with electronic components
Resolution Display: 320 x 240 pixels
Technology Capillary electrophoresis system for nucleic acid separation
Color White/Grey
Power Consumption Approx. 120 VA
Weight 25 kg
Real-Time Operation Yes
Operating Type Automated
Disposable No
Light Source LED
Display Type 5.7 color LCD touchscreen
Wall Mounted No
Condition Brand New
Portable No
Data Transmission Mode USB 2.0, LAN connectivity
Voltage 100240 V AC, 5060 Hz
Software Detail QIAxcel ScreenGel Software included
Noise Level <70 dB
Usage High-throughput DNA and RNA analysis for research labs
Internal Memory Provided for run storage and data processing
Attributes Low maintenance, high reproducibility, and user-friendly interface
Measurement Up to 96 samples per run

Product Description

Brand Qiagen

Model QIAxcel

Capacity 96 Wells

CAT No 9003110

Application Molecular Biology

Fully automate the fragment analysis and quality control of up to 96 samples per run with QIAxcel Connect. This capillary-electrophoresis instrument uses ready-to-run gel cartridges that eliminate tedious gel or consumable preparations. It also reduces handling errors.

High-Throughput, Precise, and Efficient Analysis

The QIAxcel Connect stands out with its capability to process up to 96 samples per run and handle as many as 288 samples every hour. Its cutting-edge capillary electrophoresis system ensures precise separation and detection, even for minimal nucleic acid amounts. This system empowers researchers to accomplish genotyping, fragment analysis, and RNA quality checks faster and more reproducibly than traditional gel-based methods.

Seamless Operation and Data Management

Equipped with a 5.7-inch color LCD touchscreen and bundled QIAxcel ScreenGel Software, this instrument ensures intuitive control for both routine users and advanced researchers. The system's robust connectivity options-including USB, LAN, and data cable interfaces-enable easy data transfer and synchronization with other machines, facilitating smooth workflow integration and post-run data analysis.

FAQ's of Qiagen QIAxcel Connect:

Q: How does the QIAxcel Connect improve nucleic acid analysis workflows?

A: The QIAxcel Connect automates sample processing, handles up to 96 samples per run, and delivers results in 1-4 minutes per sample. Its integrated cooling, intuitive touchscreen, and reliable QIAxcel ScreenGel Software decrease hands-on time, boost throughput, and eliminate the need for conventional gel preparation, thereby enhancing efficiency and reproducibility in research labs.

Q: What types of applications is the QIAxcel Connect suitable for?

A: This instrument is optimized for a range of nucleic acid applications, including fragment analysis, genotyping, PCR product quality control, and RNA analysis. Its compatibility with QIAxcel DNA & RNA Assay Kits ensures flexibility across various research protocols.

Q: When should laboratories consider using the QIAxcel Connect over traditional electrophoresis?

A: Laboratories should choose the QIAxcel Connect when high-throughput capacity, fast turnaround, greater sensitivity (down to 0.1 ng/l DNA), and reduced manual intervention are essential. It is especially advantageous for projects requiring repeated, large-scale nucleic acid separations with high reproducibility.

Q: Where can the QIAxcel Connect operate effectively?

A: The instrument is suitable for research labs with operating conditions of 15-30C and 20-80% non-condensing humidity. Its robust plastic housing and compact size (47 x 47 x 36 cm) allow convenient placement on most standard laboratory benches.

Q: What is the process for analyzing samples using the QIAxcel Connect?

A: Users simply load up to 96 samples onto the instrument, select the appropriate assay and parameters through the touchscreen or PC interface, and let the automated system handle the rest. Data are processed and stored internally and can be exported via USB or LAN for further analysis.

Q: How does the QIAxcel Connect benefit end users in terms of maintenance and reliability?

A: With its low maintenance requirements, built-in cooling system for capillary arrays, and sturdy construction, the QIAxcel Connect provides consistent reliability. Its high reproducibility ensures trustworthy results, while the automated operation minimizes routine maintenance and instrument downtime.
